Product Overview:

The main unit used to control any other expansion unit (incompatible with MI8O4, MO4L, and MA4) can also work independently

As the main unit: controlling more complex systems to provide protection for large machinery with multiple sensors

As an independent: control small machinery connected to up to 4 safety devices, including 1 safety light curtain, 1 emergency stop, 1 magnetic sensor, and 1 dual hand switch

Safety level: PL e

Safe input: 8 digital inputs

Security level (SIL/PL): SIL 3- SILCL 3- PL e - Cat four

Working temperature (° C): -10 to 55

Signal display: LED indicates working status and fault diagnosis. LED indications: input, OSSD output, reset request, and status output conditions

Safe output type: 2 OSSD PNP (at 400 mA, 24 VDC), self controlled, with short circuit, overload, and parity reverse protection functions

Connection: Removable terminal block, screw contacts

MTTFD (ISO 13849-1) Age: 30 one hundred

PFHD (IEC 61508): 6,86E-09

Safe output quantity: 2 pairs of OSSD (400 mA)

Programmable signal output: 2 PNP (100 mA)

Test output: 4

Storage temperature (° C): -20+ eighty-five

MSC connector: None

Connected to MSC bus: Yes

Start/restart output and EDM: 2

MCM casing: Yes

USB input: Yes

Packaging dimensions W x H x L (mm): 36 x 127 x 113

Power supply (VDC): 24 ± 20%

Dimensions HxWxD (mm): 108 x 22,5 x 114,5

Protection level: IP 20 shell - IP 2X terminal block

Tightening method: Guide rail fastening, in accordance with EN 50022-35 standard

Gross weight (g): 206,8

Contact information: 15359213550

Contact person: He Gong

Email: geabbdcs@gmail.com   386353502@qq.com

Official website: https://www.gyamazon.com , http://www.geabb.com

Additional input unit

8 digital inputs, 4 test outputs

Safety level: PL e

Safe input: 8 digital inputs

Security level (SIL/PL): SIL 3- SILCL 3- PL e - Cat four

Working temperature (° C): -10 to 55

Signal display: LED indicates working status and fault diagnosis. LED indication of input conditions

Connection: Removable terminal block, screw contacts

Test output: 4
