Product Overview:

The main unit used to control any other expansion units (incompatible with MI8O4, MO4L, and MA4) can also work independently

As the main unit: controlling more complex systems, providing protection for large machinery with multiple sensors

As an independent: control small machinery connected to up to 4 safety devices, namely 1 safety light curtain, 1 emergency stop, 1 magnetic sensor, and 1 two handed switch

Safety level: PL e

Safe input: 8 digital inputs

Safety level (SIL/PL): SIL 3- SILCL 3- PL e - Cat four

Working temperature (° C): -10 to 55

Signal display: LED indicates working status and fault diagnosis. LED indications: input, OSSD output, reset request, and status output conditions

Safe output type: 2 OSSD PNP (at 400 mA, 24 VDC), self controlled, with short circuit, overload, and parity reverse protection functions

Connection: detachable terminal block, screw contacts

MTTFD (ISO 13849-1) Age: 30 one hundred

PFHD (IEC 61508): 6,86E-09

Safe output quantity: 2 pairs of OSSD (400 mA)

Programmable signal output: 2 PNP (100 mA)

Test output: 4

Storage temperature (° C): -20+ eighty-five

MSC connector: None

Connected to MSC bus: Yes

Start/restart output and EDM: 2

MCM Housing: Yes

USB input: Yes

Packaging dimensions W x H x L (mm): 36 x 127 x 113

Power supply (VDC): 24 ± 20%

Size HxWxD (mm): 108 x 22,5 x 114,5

Protection level: IP 20 for enclosure - IP 2X for wiring board

Tightening method: Guide rail fastening, in accordance with EN 50022-35 standard

Gross weight (g): 206,8

Contact information: 15359213550

Contact person: He Gong

Email: geabbdcs@gmail.com 386353502@qq.com

Official website: https://www.gyamazon.com , http://www.geabb.com

Main technical indicators

(1) Working voltage:

Bus voltage: Bus 24V

Power supply voltage: DC24V

(2) Monitoring current:

Bus current ≤ 1mA

Power supply current ≤ 6mA

(3) Action current: Bus current ≤ 4mA

Power supply current ≤ 35mA

(4) Wire system: connected to the controller using a non polarity signal two bus, and connected to the DC24V power supply using a non polarity power two bus

(5) Output capacity: DC24V/1A (the sum of two sets of output capacities is DC24V/1A)

(6) Output control method: pulse and level (relay normally open/normally closed passive contact output, relay closing time is 10s when pulse is activated)

(7) Factory setting: Two normally open inspection lines

(8) Usage environment:

Temperature: -10 ℃~+55 ℃

Relative humidity ≤ 95%, no condensation

(9) Shell protection level: IP30

(10) Overall dimensions:

110mm × 86mm × 43mm (with bottom shell)
