Product Introduction

The canopen bus fiber optic communication module supports field buses based on CAN2.0A/B protocol, including standard buses such as CAN, DeviceNet, CANOoen, SDS, NMEA2000, SAE J1939, SAE J2284, etc. The canopen bus fiber optic communication module has independent dual bus electrical interfaces and two fiber optic interfaces, providing redundant dual bus structure and fiber redundant ring network function, Shenzhen Xunji Technology Co., Ltd. is an industrial network equipment provider that provides fiber optic redundant long-distance transmission and relay functions for redundant dual network systems. The equipment adopts new technologies and is the first to launch products with innovative functions in the industry

characteristic

*Supports logically independent dual CAN buses, including CAN2.0 A and CAN2.0 B, with 32 predetermined communication rates

*DeviceNet and CANOoen buses support rate adaptation or manual setting of all their standard rates

*Flexible selection of 1-2 CAN ports and 1-2 155M fiber optic interfaces, supporting redundant dual network fiber optic ring topology

*A fiber optic distance of over 60km, 155Mb/s, and a high-speed optical interface better support long-distance reliable transmission of burst data

*Six dual color LED status indicators, fiber optic link and power failure relay output alarms

*Lightning protection for 4000V electrical interface, 1.5 A overcurrent, 600W surge protection. Industrial grade design, EMC testing certification

*DC9-36V wide redundant dual power supply, DC1500V power isolation, reverse protection

*IP30 protection level, corrugated aluminum reinforced casing, using standard industrial 35mm guide rail installation method

Performance indicators:

Data electrical interface

*1-2 5Pin terminal interfaces, in accordance with CiA organization recommendations and ODVA organization recommendations

*Supports CAN BUS/DeviceNet/CANOpen bus standards

*Communication speed: DeviceNet/CANOpen all and common CAN speed levels, up to 1M

*Equipped with 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection functions;

*Terminal resistor: This machine is equipped with an optional 120R terminal resistor, which can be added by shorting pin 1 and pin 5 of the 5Pin data electrical interface.

Fiber optic interface

*Fiber wavelength: multimode 850nm, 1310 nm; Single mode 1310 nm, 1550 nm.

*Transmission fiber: multimode 50/125 um, 62.5/125 um, 100/140 um; Single mode 8.3/125um, 9/125um, 10/125um.

*Transmission distance: Multi mode 2Km, single mode 20Km, optional for further distances.

*Fiber optic interface types: SC, FC, ST optional, standard SC optical interface.

Power supply and protection

*Power supply: Dual power redundant input, DC (9-36) V, typical DC24V, power consumption less than 4W, with DC1500V voltage isolation and reverse protection function, industrial terminal interface

*Relay alarm output: Fiber optic link fault and power supply fault alarm output, contact capacity: DC48V/1 A, industrial terminal interface

mechanical properties

*Overall dimensions: 132mm * 105mm * 52mm (height * depth * width)

*Shell: IP30 protection level, corrugated aluminum reinforced casing

*Installation method: 35mm guide rail installation

*Net weight: 800g

work environment

*Working temperature: -10-70 ℃ (-40~+85 ℃ wide temperature optional)

*Relative humidity: ≤ 90% (non condensing)

*Storage temperature: -40~80 ℃

Can (canbus, canopen, devicenet) bus dual network redundant fiber optic ring network repeaters, unlike devices on the market, mainly solve the problem of high-speed long-distance transmission

Contact information: 15359213550

Contact person: He Gong

Email: geabbdcs@gmail.com   386353502@qq.com

Official website: https://www.gyamazon.com , http://www.geabb.com

Interface parameters

Bus protocol PROFINET

UTP or STP with a data transmission medium of Class 5 or above (recommended STP)

Bus connection method 2 * RJ45

Transmission rate 100 Mbps

Transmission distance ≤ 100m (station distance)

Electrical isolation has

technical parameter

Power supply 18-36VDC

Weight 170g

Size 100 × ninety-six × 35mm

Protection level IP20

Working temperature -10~60 ℃

Storage temperature -20~75 ℃

Relative humidity 95%, no condensation

Digital output

Rated voltage 24VDC (± 25%)

Signal points 32

Signal type PNP

Load type resistive load, inductive load

Single channel rated current Max: 500mA

Port protection overcurrent protection

Isolation and withstand voltage 500V

Channel indicator light green LED light
