Product description:

Primary Switch Mode Power Supply EPSITRON PRO Power

Technical Data
Sensor connection	A, A, B, B, C, C
Current consumption (internal)	110 mA
Counter	32 bits binary
Max. operating frequency	250 kHz
Quadrature decoder	4-fold report
Zero impulse latch	32 bits
Commands	read, set, enable
Voltage supply	24 V DC (-15 % ... +20 %)
Current consumption (typ.)	35 mA without load
Operating voltage of sensor	5 V DC
Sensor max. output current	300 mA
Internal bit width	1 x 32 bits data
	1 x 8 bits control/status
Digital outputs	(N1, N2)
Output voltage	24 V DC
Output current (max.)	0.5 A short-circuit protected
Digital inputs	(Latch, Gate, Ref)
Signal voltage	(0) -3 V ... +5 V DC
Signal voltage	(1) 15 V ... 30 V DC
Input current (typ.)	Latch 5 mA, Gate 7 mA, Ref. 7 mA
Wire connection	CAGE CLAMP
