并行应用 | RGCP-3400 系列　　伍德沃德的双模块化冗余发电机组控制面板 (RGCP) 在数据中心、医院或关键工业过程等关键任务应用中提供额外的电力系统可靠性，在这些应用中，停电成本大大超过冗余控制系统的安装成本. 基于流行的 easYgen-3400 系列发电机组控制，RGCP 包括行业先的 easYgen-3000 系列并联发电机组控制的所有特性、功能和经过验证的质量。　并行应用 | EASYGEN-2000系列　easYgen-2000™ 系列是一款结构紧凑、经济实惠的发电机组控制和保护套件，用于在孤岛运行或单个单元与公用事业的并联运行中同步和负载共享多达 16 台发电机组。其集成的负载相关启动/停止编程允许您定义发电机组如何上线和下线以支持不断变化的负载需求。它甚至可以与不同尺寸的发动机混合使用，因此您可以在优化燃油效率的同时保持所需的旋转储备。　　easYgen-2200 | easYgen-2300 | easYgen-2500

　　非并行应用 | EASYGEN-1000系列　　伍德沃德 easYgen-1000 系列专为具有自动转换功能的关键备用或主电源应用中使用的单发电机组而设计。控制器包括专门构建的算法和逻辑，用于启动、停止、控制和保护发电机组、打开/关闭断路器和具有自动转换功能的电源监控。伍德沃德的 easYgen1000 系列 AMF 发电机组控制器配备了先进的通信接口，可为 OEM 发电机组包装商提供卓越的多功能性和价值。

　　easYgen-1400 | easYgen-1600 | easYgen-1700 | easYgen-180　　非并行应用 | EASYGEN-100系　　伍德沃德 easYgen-100 系列专为隔离备用或主电源应用中使用的单发电机组而设计。控制器包括用于启动、停止、控制和保护发电机组以及打开/关闭断路器的专用算法和逻辑。伍德沃德的 easYgen-100 系列发电机组控制器配备了先进的通信接口，可为 OEM 发电机组包装商提供卓越的多功能性和价值。

　　easYgen-400 | easYgen-600 | easYgen-800

　　伍德沃德通过 easYgen-3000XT 系列控制器提高了发电机组并联控制和电源管理系统的标准。这些控制器配备了易于配置的标准化软件，而且可以轻松针对个别应用进行定制。增强的连接性可实现与其他控件和通信系统的快速安全接口，而改进的硬件是上一代 easYgen-3000 系列控件的直接替代品

　　Woodward DSLC-2™(数字同步器和负载控制)是一种基于微处理器的同步器和负载控制，设计用于三相交流发电机。DSLC-2 将同步器、负载传感器、负载控制、死母线闭合系统、VAR、功率因数和过程控制组合在一个功能强大的组件中。　有关 DSLC 的更多信息，请访问　Woodward MSLC-2™ 是一种基于微处理器的负载控制，专为配备我们的 DSLC-2™(数字同步器和负载控制)的三相发电站而设计。伍德沃德将初的 MSLC 与十年的应用经验相结合，开发出新的 MSLC-2。伍德沃德的 easYgen-3000™ 系列并联发电机组控制器为 OEM 开关设备制造商、发电机包装商和系统集成商提供了卓越的多功能性和价值。easYgen-3000 将完整的引擎式发电机控制和保护与先进的对等并联功能和创新功能结合在一个坚固、有吸引力且用户友好的产品包中。其集成的 LogicsManager™ 可编程逻辑功能提供了出色的应用灵活性，通常可以消除对额外 PLC 控制的需求，但可以根据需要轻松地与 SCADA 或基于 PLC 的控制系统集成。easYgen-2000™ 系列是一款结构紧凑、经济实惠的发电机组控制和保护套件，用于在孤岛运行或单个单元与公用事业的并联运行中同步和负载共享多达 16 台发电机组。其集成的负载相关启动/停止编程允许您定义发电机组如何上线和下线以支持不断变化的负载需求。它甚至可以与不同尺寸的发动机混合使用，因此您可以在优化燃油效率的同时保持所需的旋转储备。　用于不同应用的并联发电机组控制器　伍德沃德的 easYgen-3000™ 系列并联发电机组控制器为 OEM 开关设备制造商、发电机包装商和系统集成商提供了卓越的多功能性和价值。easYgen-3000 将完整的引擎式发电机控制和保护与先进的对等并联功能和创新功能结合在一个坚固、有吸引力且用户友好的产品包中。其集成的 LogicsManager™ 可编程逻辑功能提供了出色的应用灵活性，通常可以消除对额外 PLC 控制的需求，但可以根据需要轻松地与 SCADA 或基于 PLC 的控制系统集成。

　　easYgen-3000 为您提供了针对许多不同的分布式发电应用标准化单个、经济实惠的发电机组控制器的优势——从独立的紧急备用电源到复杂的分段配电系统中多达 32 个发电机组的并联负载共享，具有多个公用事业饲料和决胜局。

　　常见的eaSYgen 3000应用应急备用：数据中心、医院、商业和工业设施分布式发电 (DG)：用于峰值需求响应的公用事业可调度电力孤岛主电源：石油和天然气勘探、海洋、偏远村庄、租赁/移动

　　微电网：军队、政府、净零社区、大学

　　公用事业并联：调峰、需求削减　热电联产 (CHP)：废水处理、沼气生产/控制

　　开关设备升级：发电机控制改造以增加负载共享/并联能力　easYgen 3000 特性与优势

　　所有 easYgen-3000 系列型号都包括以下标准功能：　真正的 RMS 电压和电流感测(发电、母线和电源)以降低对谐波的敏感性　与发动机 ECU 的 CAN 网络通信/控制(支持标准 SAE-J1939 协议和多种专有发动机 OEM 协议)

　　用于 SCADA 信号和外部控制的串行 Modbus RTU(从站)通信　使用 Woodward ToolKit 服务工具通过 PC/笔记本电脑进行配置

　　与 RP-3000 远程面板的连接，可通过 CANopen 协议在远 250 米的距离内对 easYgen-3000 控制器进行完整的通知、控制和配置　合规机构/海事*批准：CE、UL/cUL、CSA、GOST-R、ABS、劳埃德船级社　　easYgen-3000 系列提供

　　AMF(自动电源故障)检测、去耦和紧急运行，带死母线关闭

　　自动同步：相位匹配、正/负滑频、启动(死场)并联

　　断路器合/分闸控制：仅 GCB、GCB 和 MCB(ATS 功能)或外部(无)控制

　　多 32 台发电机组的比例负载分配(等时或下垂)，无论个体大小如何

　　基本负载、进出口控制、不对称负载(通过外部基本负载输入)　自动负载依赖启动/停止以提高发电系统效率

　　异步(感应)发电机控　　发动机和发电机保护功能，具有完全可编程的设　　楷　　easYgen-3000XT 系列控制器提供三个基本包，每个包具有三个变体：　门装式(塑料外壳　　后面板安装(金属外壳)　低环境温度(塑料外壳)　e asYgen-3200XT-P1：这是“标准并联”门装式前面板型号，适用于单个发电机组的隔离运行或多达 32 台发电机组在孤岛和/或并联运行中与单个公用事业的负载共享。easYgen 3100XT-P1 是一款后面板型号，采用坚固的金属外壳，不带显示屏。精密的触摸屏远程面板 (RP-3000XT) 作为操作员控制面板补充了所有 easYgen-3000XT 系列产品。easYgen-3200XT-P1-LT 专为户外应用设计，可在低至 -40° C 的温度下运行。
模块是通过内部的加速度来测量振动的。模块可以同时测量X和Y方向的振动。用户可以选择监测一个或两个振动监测保护模块。
2.
模块内部还提供有报警检测功能,报警限值和延迟时间可自行设定。设定延迟时间可以防止错误的报警。报警电路中配置有继电器输出端口,当振动超限报警时,可以启动外部的报警系统或者直接保护机组停机。　IS220YDIAS1A 兼容性　YDIA I/O 包中包含一个内部处理器板。Parallel Applications | The RGCP-3400 series Woodward's Dual Modular Redundant Generator Control Panel (RGCP) provides additional power system reliability in critical mission applications such as data centers, hospitals, or critical industrial processes, where power outage costs greatly exceed the installation costs of redundant control systems Based on the popular easYgen-3400 series generator set control, RGCP includes all the characteristics, functions, and verified quality of the industry-leading easYgen-3000 series parallel generator set control. Parallel Applications | EASYGEN-2000 Series easYgen-2000 ™ The series is a compact and cost-effective control and protection kit for generator sets, designed to synchronize and load share up to 16 generator sets in isolated island operation or parallel operation of individual units with utilities. Its integrated load related start/stop programming allows you to define how the generator set goes online and offline to support constantly changing load demands. It can even be mixed with engines of different sizes, so you can optimize fuel efficiency while maintaining the required rotational reserve. easYgen-2200 | easYgen-2300 | easYgen-2500



Non parallel applications | EASYGEN-1000 series Woodward easYgen-1000 series is designed for single generator units used in critical backup or main power applications with automatic conversion capabilities. The controller includes specially constructed algorithms and logic for starting, stopping, controlling, and protecting the generator set, opening/closing circuit breakers, and power monitoring with automatic switching function. Woodward's easYgen1000 series AMF generator set controller is equipped with the most advanced communication interface, providing excellent versatility and value for OEM generator set packagers.



EasYgen-1400 | easYgen-1600 | easYgen-1700 | easYgen-180 Non parallel Applications | EASYGEN-100 series Woodward easYgen-100 series is designed specifically for isolating single generator sets used in backup or main power applications. The controller includes dedicated algorithms and logic for starting, stopping, controlling, and protecting the generator set, as well as opening/closing circuit breakers. Woodward's easYgen-100 series generator controller is equipped with the most advanced communication interface, providing excellent versatility and value for OEM generator package manufacturers.



easYgen-400 | easYgen-600 | easYgen-800



Woodward has improved the standards of parallel control and power management systems for generator sets through the easYgen-3000XT series controller. These controllers are equipped with standardized software that is easy to configure and can be easily customized for individual applications. Enhanced connectivity enables fast and secure interfaces with other controls and communication systems, while improved hardware is a direct replacement for the previous generation easYgen-3000 series controls



Woodward DSLC-2 ™ (Digital synchronizer and load control) is a microprocessor based synchronizer and load control designed for three-phase AC generators. DSLC-2 combines synchronizer, load sensor, load control, dead bus closure system, VAR, power factor, and process control into a powerful component. For more information about DSLC, please visit Woodward MSLC-2 ™ It is a microprocessor based load control specifically designed for equipping our DSLC-2 ™ Designed for three-phase power plants with digital synchronizers and load control. Woodward combined the initial MSLC with ten years of application experience to develop the new MSLC-2. Woodward's easYgen-3000 ™ The series parallel generator controller provides excellent versatility and value for OEM switchgear manufacturers, generator packagers, and system integrators. EasYgen-3000 combines complete engine generator control and protection with advanced peer-to-peer parallel and innovative features in a robust, attractive, and user-friendly product package. Its integrated LogicsManager ™ Programmable logic functions provide excellent application flexibility, typically eliminating the need for additional PLC control, but can be easily integrated with SCADA or PLC based control systems as needed. easYgen-2000 ™ The series is a compact and cost-effective control and protection kit for generator sets, designed to synchronize and load share up to 16 generator sets in isolated island operation or parallel operation of individual units with utilities. Its integrated load related start/stop programming allows you to define how the generator set goes online and offline to support constantly changing load demands. It can even be mixed with engines of different sizes, so you can optimize fuel efficiency while maintaining the required rotational reserve. Woodward's easYgen-3000 parallel generator set controller for different applications ™ The series parallel generator controller provides excellent versatility and value for OEM switchgear manufacturers, generator packagers, and system integrators. EasYgen-3000 combines complete engine generator control and protection with advanced peer-to-peer parallel and innovative features in a robust, attractive, and user-friendly product package. Its integrated LogicsManager ™ Programmable logic functions provide excellent application flexibility, typically eliminating the need for additional PLC control, but can be easily integrated with SCADA or PLC based control systems as needed.



EasYgen-3000 provides you with the advantage of standardizing a single, affordable generator set controller for many different distributed generation applications - from independent emergency standby power to parallel load sharing of up to 32 generator sets in a complex segmented distribution system, with multiple utility feeds and a winning streak.



Common eaSYgen 3000 application emergency backup: data center, hospital, commercial and industrial facilities distributed generation (DG): utilities for peak demand response schedulable power island main power supply: oil and gas exploration, ocean, remote villages, leasing/mobile



Microgrid: military, government, net zero community, university



Parallel connection of public utilities: peak shaving, demand reduction, cogeneration (CHP): wastewater treatment, biogas production/control



Switchgear upgrade: Generator control modification to increase load sharing/parallel capability easYgen 3000 features and advantages



All easYgen-3000 series models include the following standard features: true RMS voltage and current sensing (power generation, busbar, and power supply) to reduce sensitivity to harmonics and CAN network communication/control of engine ECU (supporting standard SAE-J1939 protocol and various proprietary engine OEM agreements)



Serial Modbus RTU (slave station) communication for SCADA signals and external control is configured using the Woodward ToolKit service tool through a PC/laptop computer



The connection to the RP-3000 remote panel allows for complete notification, control, and configuration of the easYgen-3000 controller within a maximum distance of 250 meters through the CANopen protocol. Compliance agencies/maritime * approvals include CE, UL/cUL, CSA, GOST-R, ABS, and Lloyd's Register of Shipping easYgen-3000 series



AMF (Automatic Power Failure) detection, decoupling, and emergency operation with dead bus closure



Automatic synchronization: phase matching, positive/negative sliding frequency, start (dead field) parallel connection



Circuit breaker closing/opening control: only GCB, GCB, and MCB (ATS function) or external (no) control



Proportional load distribution (isochronous or drooping) for up to 32 generator units, regardless of individual size



Basic load, import and export control, asymmetric load (through external basic load input) automatic load dependent start/stop to improve power generation system efficiency



Asynchronous (induction) generator control engine and generator protection functions, with fully programmable easYgen-3000XT series controllers providing three basic packages, each with three variants: door mounted (plastic housing rear panel installation (metal housing) low ambient temperature (plastic housing) e asYgen-3200XT-P1: This is a "standard parallel" door mounted front panel model, Suitable for isolated operation of a single generator set or for up to 32 generator sets sharing load with a single utility in isolated and/or parallel operation. EasYgen 3100XT-P1 is a rear panel model with a sturdy metal casing and no display screen. The precision touch screen remote panel (RP-3000XT) complements all easYgen-3000XT series products as an operator control panel. EasYgen-3200XT-P1-LT is designed specifically for outdoor applications and can operate at temperatures as low as -40 ° C.

The module measures vibration through internal acceleration. The module can simultaneously measure vibrations in both the X and Y directions. Users can choose to monitor one or two vibration monitoring protection modules.

two

The module also provides alarm detection function internally, and the alarm limit and delay time can be set by oneself. Setting a delay time can prevent erroneous alarms. The alarm circuit is equipped with a relay output port, which can activate the external alarm system or directly protect the unit from shutdown when the vibration exceeds the limit alarm. The IS220YDIAS1A compatibility YDIA I/O package includes an internal processor board.
