PCS9100直线位移，比如拉伸、膨胀、直径、锥度、厚度、偏心度、差压、液位、力、重量。由于其具有无滑动触点、功耗低、分辨率高、频率高、重复性好、可靠性好、使用寿命长等优点，因而被广泛应用于高温、高湿、粉尘、烟气等恶劣环境。主要用来监测汽轮机机壳膨胀、液压油缸活塞定位、阀门位置和材料试验机。驰捷公司生产的LVDT系列主要分为直流系列和交流系列

1.供电电源:10VDC-30VDC;±5VDC-±15VDC，-24VDC

2.量程范围：0mm-25mm或0mm-500mm

3.输出方式：4mA-20mA;1VDC-5VDC;-5VDC _ +5VDC;0VDC_-10VDC

4.非线性误差：＜±0.5%

5.工作储存环境：温度-55℃-150℃   相对湿度＜95%（无冷凝）
