FC-2979MEP5-504806
FBM201/b/c/d模拟输入（0至20 mA，0至100 mV，0至5 V，0
至10 V dc）环境规范
环境规范
操作存储
温度•FBM201/b/c/d：
-20至+70°C（-4至+158°F）
•终端组件–PA：
-20至+70°C（-4至+158°F）
-40°至+70°C（-40°至158°F）
相对湿度5至95%（非冷凝）
海拔-300至+3000米（-1000至+10000英尺）-300至+12000米（-1000至+40000英尺）
适用于ISA标准S71.04中定义的G3级（恶劣）环境的污染，基于
根据EIA标准364-65，三级进行暴露试验。
从5到500 Hz的振动7.5 m/s2（0.75 g）
注：该模块的环境限制可能会因以下类型而增强：
包含模块的机柜。参考适用的产品规范
描述要使用的外壳类型的表（PSS）。
8 PSS 41H-2S201，版本A
物理规格
FBM201/b/c/d模拟输入（0至20 mA，0至100 mV，0至5 V，0
至10 V dc）
物理规格
安装•FBM201/b/c/d：
模块安装在模块化基板上。基板可以是
安装在DIN导轨上（水平或垂直），或水平安装在19-
使用安装套件的英寸机架。或者，模块安装在
100系列转换安装结构。见标准200系列
基板（PSS 41H-2SBASPLT）或100系列转换安装
结构（PSS 41H-2W8）的详细信息。
•终端组件：
TA安装在DIN导轨上，可适应多种DIN导轨样式
包括32毫米（1.26英寸）和35毫米（1.38英寸）。
重量•FBM201/b/c/d：
约284克（10盎司）
•终端组件：
◦ 压缩：
约181克（0.40磅）
◦ 环形凸耳：
249克（0.55磅）近似值
尺寸•FBM201/b/c/d：
◦ 高度：
102毫米（4英寸）
114毫米（4.5英寸），带安装凸耳
◦ 宽度：
45毫米（1.75英寸）
◦ 深度：
104毫米（4.11英寸）
•终端组件：
见15页尺寸-标称。
零件号•FBM201：
RH914SQ
•FBM201b：
RH922YH
•FBM201c：
RH922YJ
•FBM201d：
RH922YK
•终端组件：
见功能规范-终端组件，12页。
PSS 41H-2S201，版本A 9
FBM201/b/c/d模拟输入（0至20 mA，0至100 mV，0至5 V，0
至10 V dc）物理规格
终端电缆•电缆长度：
高达30米（98英尺）
•电缆材料：
聚氨酯或低烟无卤（LSZH）
•终端电缆类型：
类型1–见13页表2
•基板至主TA电缆连接：
◦ FBM基板端部：
37针D-超小型
◦ 终端组件端部：
25针D-超小型
施工-终止
组件•材料：
◦ 聚酰胺（PA），压缩
◦ PA，环形凸耳
现场终端连接•可接受的压缩型接线尺寸：
◦ 实心/绞合/AWG：
0.2至4 mm2/0.2至2.5 mm2/24至12 AWG
◦ 用套圈绞合：
0.2至2.5 mm2，带或不带塑料环
•可接受的环形接线片类型接线尺寸：
◦ #6个尺寸的连接器（0.375英寸（9.5毫米）
◦ 0.5至4 mm2/22 AWG至12 AWG
10 PSS 41H-2S201，版本A
终端组件和电缆
FBM201/b/c/d模拟输入（0至20 mA，0至100 mV，0至5 V，0
至10 V dc）
终端组件和电缆
现场输入信号通过DIN导轨安装终端连接到FBM子系统
电无源组件（参见5页图1）。助教
FBM201/b/c/d模块有以下几种形式：
•使用聚酰胺（PA）材料的压缩螺钉类型
•使用聚酰胺（PA）材料的环耳型
有关使用的TA列表，请参阅功能规范-终端组件，12页
带有FBM201/b/c/d模块。
可移动终端电缆通过一个
安装FBM的基板上的现场连接器。终端电缆为
提供以下材料：
•聚氨酯
•低烟无卤（LSZH）
终端电缆有多种长度，长可达30米（98英尺），
允许将终端组件安装在外壳或
相邻外壳。请参阅13页的表2，了解与
FBM201/b/c/d模块的TA。
PSS 41H-2S201，版本A 11
FBM201/b/c/d模拟输入（0至20 mA，0至100 mV，0至5 V，0
至10 V dc）功能规范-终端组件
功能规范.终端组件
FBM型输入信号TA部分
数字
结束
类型（b）
TA电缆
类型（c）
TA证书。
类型（d）
PA（a）
FBM201 8通道，0至20
mA dc，无源
馈通
FBM201通道
隔离
RH916XG（e）C
P0917JK 1 1，2（e）
RL
FBM201b 8通道，0到100
中压直流，无源
馈通
FBM201b通道
隔离
RH922ZM
C.1.2
FBM201c 8通道，0至5 V
直流，无源
馈通
FBM201c通道
隔离
RH922ZN
C.1.2
FBM201d 8通道，0至10 V
直流，无源
馈通
FBM201d通道
隔离
RH922ZP
C
1 1, 2
P0926SQ RL
（a） PA是聚酰胺，额定温度为-20至+70°C（-4至+158°F）。
（b） C=带压缩端子的TA；RL=TA，带环形接线片端子。
（c） 电缆零件号和规格见13页表2 FC-2979MEP5-504806
 FC-2979MEP5-504806
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc) Environmental Specifications
Environmental Specifications
Operating Storage
Temperature • FBM201/b/c/d:
-20 to +70°C (-4 to +158°F)
• Termination Assembly – PA:
-20 to +70°C (-4 to +158°F)
-40° to +70°C (-40° to 158°F)
Relative Humidity 5 to 95% (noncondensing)
Altitude -300 to +3,000 m (-1,000 to +10,000 ft) -300 to +12,000 m (-1,000 to +40,000 ft)
Contamination Suitable for use in Class G3 (Harsh) environments as defined in ISA Standard S71.04, based
on exposure testing according to EIA Standard 364-65, Class III.
Vibration 7.5 m/s2 (0.75 g) from 5 to 500 Hz
NOTE: The environmental limits of this module may be enhanced by the type of
enclosure containing the module. Refer to the applicable Product Specification
Sheet (PSS) that describes the type of enclosure to be used.
8 PSS 41H-2S201, Rev A
Physical Specifications
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc)
Physical Specifications
Mounting • FBM201/b/c/d:
The modules mount on a modular baseplate. The baseplate can be
mounted on a DIN rail (horizontally or vertically), or horizontally on a 19-
inch rack using a mounting kit. Alternatively, the modules mount on a
100 Series conversion mounting structure. See Standard 200 Series
Baseplates (PSS 41H-2SBASPLT) or 100 Series Conversion Mounting
Structures (PSS 41H-2W8) for details.
• Termination Assembly:
The TA mounts on a DIN rail and accommodates multiple DIN rail styles
including 32 mm (1.26 in) and 35 mm 1.38 in).
Weight • FBM201/b/c/d:
284 g (10 oz) approximate
• Termination Assembly:
◦ Compression:
181 g (0.40 lb) approximate
◦ Ring Lug:
249 g (0.55 lb) approximate
Dimensions • FBM201/b/c/d:
◦ Height:
102 mm (4 in)
114 mm (4.5 in) with mounting lugs
◦ Width:
45 mm (1.75 in)
◦ Depth:
104 mm (4.11 in)
• Termination Assembly:
See Dimensions - Nominal, page 15.
Part Numbers • FBM201:
RH914SQ
• FBM201b:
RH922YH
• FBM201c:
RH922YJ
• FBM201d:
RH922YK
• Termination Assemblies:
See Functional Specifications - Termination Assemblies, page 12.
PSS 41H-2S201, Rev A 9
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc) Physical Specifications
Termination Cables • Cable Lengths:
Up to 30 m (98 ft)
• Cable Materials:
Polyurethane or Low Smoke Zero Halogen (LSZH)
• Termination Cable Type:
Type 1 – See Table 2, page 13
• Baseplate to Main TA Cable Connection:
◦ FBM Baseplate End:
37-pin D-subminiature
◦ Termination Assembly End:
25-pin D-subminiature
Construction – Termination
Assembly • Material:
◦ Polyamide (PA), compression
◦ PA, ring lug
Field Termination Connections • Compression-Type Accepted Wiring Sizes:
◦ Solid/Stranded/AWG:
0.2 to 4 mm2 /0.2 to 2.5 mm2 /24 to 12 AWG
◦ Stranded with Ferrules:
0.2 to 2.5 mm2 with or without plastic collar
• Ring-Lug Type Accepted Wiring Sizes:
◦ #6 size connectors (0.375 in (9.5 mm)
◦ 0.5 to 4 mm2 /22 AWG to 12 AWG
10 PSS 41H-2S201, Rev A
Termination Assemblies and Cables
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc)
Termination Assemblies and Cables
Field input signals connect to the FBM subsystem via DIN rail mounted Termination
Assemblies, which are electrically passive (see Figure 1, page 5). TAs for the
FBM201/b/c/d modules are available in the following forms:
• Compression screw type using Polyamide (PA) material
• Ring lug type using Polyamide (PA) material
See Functional Specifications - Termination Assemblies, page 12 for a list of TAs used
with the FBM201/b/c/d modules.
A removable termination cable connects the DIN rail mounted TA to the FBM via a
field connector on the baseplate in which the FBM is installed. Termination cables are
available in the following materials:
• Polyurethane
• Low Smoke Zero Halogen (LSZH)
Termination cables are available in a variety of lengths, up to 30 meters (98 feet),
allowing the Termination Assembly to be mounted in either the enclosure or in an
adjacent enclosure. See Table 2, page 13 for a list of termination cables used with the
TAs for the FBM201/b/c/d modules.
PSS 41H-2S201, Rev A 11
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc) Functional Specifications - Termination Assemblies
Functional Specifications - Termination Assemblies
FBM Type Input Signal TA Part
Number
Termination
Type(b)
TA Cable
Type(c)
TA Cert.
Type(d)
PA (a)
FBM201 8 channels, 0 to 20
mA dc, passive
feedthrough with
FBM201 channel
isolation
RH916XG(e) C
P0917JK 1 1, 2 (e)
RL
FBM201b 8 channels, 0 to 100
mV dc, passive
feedthrough with
FBM201b channel
isolation
RH922ZM
C 1 1, 2
FBM201c 8 channels, 0 to 5 V
dc, passive
feedthrough with
FBM201c channel
isolation
RH922ZN
C 1 1, 2
FBM201d 8 channels, 0 to 10 V
dc, passive
feedthrough with
FBM201d channel
isolation
RH922ZP
C
1 1, 2
P0926SQ RL
(a) PA is polyamide rated from -20 to +70°C (-4 to +158°F).
(b) C = TA with compression terminals; RL = TA with ring lug terminals.
(c) See Table 2, page 13 for cable part numbers and specifications.
(d) See Table 1, page 13 for termination assembly certification definitions.
(e) Polyamide RL supersedes the PVC RL. This is not a RoHS part.the modules provide visual
status indications of Fieldbus Module functions.
Modular Baseplate Mounting
The modules mount on a modular baseplate (see Figure 1, page 5), which
accommodates up to four or eight FBMs. The modular baseplate is either DIN rail
mounted or rack mounted, and includes signal connectors for redundant fieldbus,
redundant independent dc power, and termination cables.
Fieldbus Communication
A Fieldbus Communication Module or a Control Processor interfaces the redundant 2
Mbps module Fieldbus used by the FBMs. The FBM201/b/c/d modules accept
communication from either path (A or B) of the redundant 2 Mbps fieldbus. If one path
is unsuccessful or is switched at the system level, the module continues
communication over the active path.
Termination Assemblies
Field I/O signals connect to the FBM subsystem via DIN rail mounted TAs. The TAs
used with the FBM201/b/c/d modules are described in Termination Assemblies and
Cables, page 11.
4 PSS 41H-2S201, Rev A
Overview
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc)
Figure 1 - FBM201 Subsystem – Typical
Legend
A Termination Assembly
B Termination Cable
C FBM201 RH914SQ
D Fieldbus Cables
E FBM Baseplate
F Power Cable
PSS 41H-2S201, Rev A 5
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc) Functional Specifications
Functional Specifications
Process I/O
Communications
Communicates with its associated FCM or FCP via the redundant 2 Mbps module
Fieldbus
Input Channels 8 isolated and independent channels
Input Range (each
channel)
FBM201: 0 to 20 mA dc
FBM201b: 0 to 100 mV dc
FBM201c: 0 to 5 V dc
FBM201d: 0 to 10 V dc
Input Channels (8) • Analog Accuracy (includes linearity):
±0.03% of span
Accuracy temperature coefficient: ±50 ppm/ºC
• Field Device Cabling Distance:
Maximum distance of the field device from the FBM is a function of compliance
voltage (22.8 V dc), wire resistance, and voltage drop at the field device.
• Input Channel Impedance:
FBM201: 61.5 Ω nominal
FBM201b: 10 MΩ
FBM201c: 10 MΩ
FBM201d: 10 MΩ
• Input Signal A/D Conversion:
Each channel performs A/D signal conversion using an independent Sigma-Delta
converter.
• Integration Period:
Software configurable
• Common Mode Rejection:
>100 db at 50 or 60 Hz
• Normal Mode Rejection:
>95 db at 50 or 60 Hz
• Loop Power Supply Protection
Each channel is channel-to-channel galvanically isolated, current limited, and
voltage regulated. All analog inputs are limited by their design to less than 30 mA.
If the current limit circuit shorted out, the current is limited to about 100 mA.
• Input Channel Isolation
Each channel is galvanically isolated from all other channels and earth (ground).
The module/TA withstands, without damage, a potential of 600 V ac applied for one
minute between any channel and ground, or between a given channel and any
other channel.
DANGER
HAZARD OF ELECTRIC SHOCK, EXPLOSION, OR ARC FLASH
This does not imply that these channels are intended for permanent connection to
voltages of these levels. Exceeding the limits for input voltages, as stated elsewhere
in this specification, violates electrical safety codes and may expose users to electric
shock.
Failure to follow these instructions will result in death or serious injury.
6 PSS 41H-2S201, Rev A
Functional Specifications
FBM201/b/c/d Analog Input (0 to 20 mA, 0 to 100 mV, 0 to 5 V, 0
to 10 V dc)
Power Requirements • Input Voltage Range (Redundant):
24 V dc +5%, -10%
• Consumption:
7 W
• Heat Dissipation:
3 W (maximum)
Calibration
Requirements
Calibration of the module and termination assembly is not required.
Regulatory Compliance:
Electromagnetic
Compatibility (EMC)
• European EMC Directive 2004/108/EC (Prior to April 20, 2016) and 2014/30/EU
(Beginning April 20, 2016):
Meets: EN61326-1:2013 Class A Emissions and Industrial Immunity Levels
Regulatory Compliance:
Product Safety • Underwriters Laboratories (UL) for U.S. and Canada:
UL/UL-C listed as suitable for use in UL/UL-C listed Class I, Groups A-D; Division
2; temperature code T4 enclosure based systems when connected to specified
Foxboro DCS processor modules. Communications circuits also meet the
requirements for Class 2 as defined in Article 725 of the National Electrical Code
(NFPA No.70) and Section 16 of the Canadian Electrical Code (CSA C22.1). For
more information, see Standard and Compact 200 Series Subsystem User's Guide
(B0400FA).
• European Low Voltage Directive 2006/95/EC (Prior to April 20, 2016) and 2014/35/
EU (Beginning April 20, 2016) and Explosive Atmospheres (ATEX) directive 94/9/
EC (Prior to April 20, 2016) and 2014/34/EU (Beginning April 20, 2016):
DEMKO certified as Ex nA IIC T4 for use in certified Zone 2 enclosure when
connected to specified processor modules as described in the Standard and
Compact 200 Series Subsystem User's Guide (B0400FA).
RoHS Compliance Complies with European RoHS Directive 2011/65/EU, including amending Directives
2015/863 and 2017/2102.
Marine Certification ABS Type Approved and Bureau Veritas Marine certified for Environmental Category
EC31. | | |
4年
