5.2.3.2 Skip and reset function
It is possible to reset the frame handler or skip an invalid frame from any state. This can be done by writing one to the RST or the SKIP
bit of the FHC register. Skipping a frame causes the frame handler to ignore the rest of an incoming message, without triggering any
additional interrupt. A soft reset is done after receiving the rest of invalid message or if a timeout was detected. Skipping a frame has no
effect on the cycle timer. Resetting a frame immediately resets the frame handler into its idle state and also causes a reset of the cycle
timer.
5.3 Interrupt handling
The chip utilizes two modes of interrupt handling. The active mode can be switched with the IMODE bit in the INT register. Interrupt mode
1 is active by default.
5.3.1 Mode 1
Interrupts are triggered on rising edges of the WURQ, RXRDY, TXRDY, or TOUT bits in the SPI Status. If CQ is configured as an input
in SIO mode, interrupts are also triggered on any edge of the RXD bit. Changes of the STATE bits in the SPI Status also trigger interrupts,
depending on the IMSK register settings. Trigger conditions can be the start of frame transmission or reception or reaching a defined fill
level of the buffer. An interrupt is always triggered after a frame is completely received.
Another trigger condition is any change of values in the STAT register. This is why the microcontroller should always deal with an interrupt
by reading back the STAT register. The interrupt is cleared while reading the status register.
5.3.2 Mode 2
The interrupt triggering conditions are the same as described in Interrupt mode 1. Mode 2 differs in how interrupts are handled. First, the
interrupt origin can be determined by reading the INT register. The interrupt then needs to be actively cleared by the user. This is done
by writing a one to the appropriate bit ISTAT, ICH1, or ICH2 in the INT register. The INTX pin remains in its active state until all interrupts
are cleared.
IDLE RECEIVE TRANSMIT
transmission done
reset triggered
reset triggered
start of master message first byte of
device message buffered
11 NXP Semiconductors
CM3120
ARCHIVE INFORMATION
ARCHIVE INFORMATION
5.3.3 Interrupt masking
To reduce the amount of triggered interrupts in frame handler mode, the user can deactivate the triggering of interrupts at certain
conditions in the IMSK register. All frame handler interrupts are listed in the Table 5.
The MSG interrupt is always active. By default, all other interrupts are masked. If the LVL interrupt is active, an interrupt is triggered if the
input buffer reaches a defined fill level. The current amount of buffered characters can be queried in the BLVL register. The threshold for
buffered characters which triggers the LVL interrupt is configured in the TRSH register.
 Figure 5. Interrupt Trigger Positions
It is also possible to mask the short detected (SD) interrupt of the STAT register. Otherwise an interrupt gets triggered as soon as a short
is detected.
5.4 Protection features
The CM3120 IO-Link Master integrates various features to protect the IO-Link master and connected IO-Link devices. Different
configuration options allow the user to take individual safety measures and to prevent damage.
5.4.1 Current sensing
5.4.1.1 Internal/external mode
There are two possible methods implemented to detect a high load at the IO-Link supply voltage - an internal and an external current
sensing mechanism. Both mechanisms cannot be active at the same time. The user has to choose, which one should be used for each
channel. The current sensing mode is configured by the SDINT bit in the CFG register. The SD bit in the STAT register and the SDX pins
always reflect the current sensing state.
The internal current sensing mechanism does not need any external circuitry to work, but has the limitation to only detect currents IMHS
and IMLS at the CM3120 CQ pin with a fixed current threshold. High currents IDEV from a connected device cannot be detected.
Therefore the short protection feature for devices is not feasible in this mode. The usage of an external NMOS transistor is still possible.
The external current sensing can detect high currents IMHS and IMLS at the CQ pin and IDEV of a connected device. External shunts
with a typical resistance of 0.5 Ω needs to be applied for a current threshold of 400 mA. It is possible to adjust the high current detection
threshold by changing the shunts resistance value. The voltage drop over the shunt is defined with 200 mV. Current sensing over a shunt
and an external NMOS transistor allow the usage of the short protection feature.
