通过菜单命令File-Print，您可以在屏幕上打印程序。
如果有一个驱动器连接到您的电脑硬件，您可以制作一个
通过菜单命令drive-Connect将软件连接到此驱动器
（如果有多个驱动器连接到电脑硬件，则
可以从可用驱动器列表中选择驱动器）。
注意：如果在连接DriveAP时更改驱动器语言，则
必须关闭和打开驱动器电源，然后重新连接。
此连接命令将DriveAP的操作模式更改为
离线模式。
通过菜单命令Drive-Upload上传并显示AP
连接驱动器的程序。
如果光标位于块上并按F3键，则
此块显示在信息窗口中。
如果需要，现在可以修改屏幕上的AP程序（参见
本章程序修改部分）。
通过菜单命令文件-下载下载程序
将屏幕连接到连接的驱动器。
除了上述用于上传和
下载，文件菜单中的命令在此操作系统中可用
模式
如果你想使用另一个连接到电脑的驱动器，首先
通过菜单命令drive断开当前连接的驱动器-
断开连接，然后连接到新的drive by菜单
命令驱动-连接
通过菜单命令Drive-On Line，您可以更改操作模式
将DriveAP切换到联机模式。
注意：连接驱动器的AP程序自动
在该操作模式启动期间上传并显示。
如果光标位于块上并按F3键，则
此块显示在信息窗口中。
对屏幕上程序的所有修改（参见“程序”一节
本章中的修改）
复制到连接的驱动器
离线模式
在线模式
DriveAP的使用
DriveAP用户手册3-5
注意：不要通过面板（或
由于这些变化，在联机模式期间
不会显示在屏幕上！
如果参数（或参数位）连接到
一个块，你点击这个输入引脚（或任何输出引脚），而
按住Shift键，此参数的实际值（或
输出引脚）以数字形式实时显示在屏幕上。
注意：如果您有DriveWindow并且启用了
同时使用DriveWindow和DriveAP，您可以监视
使用DriveWindow以图形方式显示参数值，同时使用DriveAP
跑步
再次单击（按住）可以删除值显示
按下Shift键）。
标准用户界面：AP程序的状态（正在运行，
屏幕上会显示已连接驱动器中的（已停止或编辑）
可以通过菜单命令Drive-Start、Drive-Stop进行更改
和驱动-编辑。
级用户界面：当前可见时间级别的状态
连接驱动器中的（运行、停止或编辑）显示在
屏幕，可以通过菜单命令“驱动-启动”进行更改
时间级别，驱动-停止此时间级别并驱动-编辑此
时间级别。
可以通过菜单命令更改所有时间级别的状态
驱动-启动所有时间级别，驱动-停止所有时间级别和
驱动-编辑所有时间级别。
连接驱动器的状态信息显示在
在驱动器状态框中实时显示。参考值
按住Shift键的同时单击屏幕，可以将其删除
钥匙
标准用户界面：所有非AP参数的列表为
显示在功能块下方的列表框中。
级用户界面：参数窗口列出所有非AP
参数。如果删除此窗口，您可以通过
按F2键（或通过菜单命令驱动-参数列表-
显示参数列表）。
可以读取参数列表中所有参数的当前值
从“驱动方式”菜单命令“驱动-参数列表-上载”
值（参数的当前值可以通过单个
单击列表中的此参数）。
您可以更改驱动方式中非AP参数的值
双击列表中所需的参数。
DVB-56T17T5305E-505087


DVB-56T17T5305E-505087

By menu command File - Print you print the program on the screen. If there is a drive connected to your PC hardware, you can make a software connection to this drive by menu command Drive - Connect (if there are more than one drive connected to the PC hardware, you can select the drive from the list of available drives). Note: If you change drive language when DriveAP is connected, you must switch drive power off and on and Connect again. This Connect command changes the operating mode of DriveAP to the Off-Line Mode. By menu command Drive - Upload you upload and display the AP program of the connected drive. If the cursor is on a block and you press the F3 key, the description of this block is displayed in the Info window. If desired, the AP program on the screen can now be modified (see Section Program Modification in this Chapter). By menu command File - Download you download the program on the screen to the connected drive. In addition to the above-mentioned menu commands for upload and download, commands in the File menu are available in this operating mode. If you want to use another drive connected to your PC, first disconnect the currently connected drive by menu command Drive - Disconnect, then make a connection to the new drive by menu command Drive - Connect By menu command Drive - On-Line you change the operating mode of DriveAP to the On-Line Mode. Note: The AP program of the connected drive is automatically uploaded and displayed during the start-up of this operating mode. If the cursor is on a block and you press the F3 key, the description of this block is displayed in the Info window. All modifications to the program on the screen (see Section Program Modification in this Chapter) during this mode are automatically copied to the connected drive Off-Line Mode On-Line Mode Use of DriveAP DriveAP User’s Manual 3-5 Note: Do not change values of AP parameters by the panel (or by some other means) during the On-Line Mode since these changes are not displayed on the screen! If a parameter (or a bit of a parameter) is connected to an input pin of a block and you click on this input pin (or on any output pin) while holding down the Shift key, the actual value of this parameter (or this output pin) is displayed numerically on the screen in real time. Note: If you have DriveWindow and you have enabled the simultaneous use of DriveWindow with DriveAP, you can monitor parameter values graphically with DriveWindow while DriveAP is running. The value display can be removed by clicking again (while holding down the Shift key) on the same pin. Standard User Interface: The state of the AP program (Running, Stopped or Edit) in the connected drive is displayed on the screen and can be changed by menu commands Drive - Start, Drive - Stop and Drive - Edit. Advanced User Interface: The state of the currently visible time level (Running, Stopped or Edit) in the connected drive is displayed on the screen and can be changed by menu commands Drive - Start This Time Level, Drive - Stop This Time Level and Drive - Edit This Time Level. The states of all time levels can be changed by menu commands Drive - Start All Time Levels, Drive - Stop All Time Levels and Drive - Edit All Time Levels. The status information of the connected drive is displayed on the screen in real time in the DRIVE STATUS box. The reference value display can be removed by clicking on it while holding down the Shift key. Standard User Interface: The list of all non-AP parameters is displayed in the list box below the function blocks. Advanced User Interface: The Parameter Window lists all non-AP parameters. If you remove this window, you can see it again by pressing the F2 key (or by menu command Drive - Parameter List - Display Parameter List). Current values of all parameters in the parameter list can be read from the drive by menu command Drive - Parameter List - Upload Values (the current value of a parameter can be read by single clicking on this parameter in the list). You can change the value of a non-AP parameter in the drive by double clicking on the desired parameter in the list.
