Drive contiguration
DCS 500 drives are freely programmable and therefore In case you want to reconfigure terminals by means of
also terminals with their in and outs can be modified in
software, please read the software description first and
their functionality.
inform yourself about the possibilities you have before
When you receive yourconverter all terminals from X3:
you start. (Never change any terminal while yourdrive
toX7: are set toa default configuration as shown below. is still connected to the mains!). After that you need to
This enables you to connect your drive according to
make sure that the correct signals are provided to your
connection example (see chapter 3) without any chang
terminals.
es.
