反馈连接器根据安装条件，可以选择不同类型的连接器来连接电机反馈电缆。可用的有：•直连接器•角连接器关于连接器类型分配到电机类型的信息，可在尺寸数据表和13.2节“反馈连接连接器”中找到。直线连接器图2.13描述了带有直线反馈连接器的电机。图2.13：带直反馈连接器角连接器的MDD电机INDRAMAT提供并交付角连接器，以便电缆插入法兰插座后的输出方向为电机的B侧。图2.14：带角度连接器的MDD电机（输出方向为B侧）左右A侧FAABGANG FAGERADSTECK反馈连接器FAWINKSTECK反馈连接器2。技术说明•DOK-电机*-MDD******-PRJ1-EN-E1,44•12.96 23用户可以更改输出方向。只需松开四个固定螺钉（见图2.15）。现在可以将接头零件以90°的增量转动到所需的位置。图2.15：标记连接器2.3的零件。电气特性端子图图图2.16所示的端子图仅为示意图。它代表了操作MDD AC伺服电机所需的所有电气连接的检查表。图2.16：端子示意图MDD电机上有以下电气连接：•电源连接•反馈连接确保重新拧紧螺钉时垫圈和电缆芯均未损坏。FABEZSTECK安装螺钉连接器外壳带螺帽的连接器零件

Feedback connector Different types of connectors can be selected for connecting the motor feedback cable depending upon the installaton conditions. Available are: • straight connector • angle connector Information about the allocation of the connector type to the motor type can be found in the dimensional data sheets and in section 13.2 "Connector for the Feedback Connections". Straight Connector Figure 2.13 depicts a motor with a straight feedback connector. Fig. 2.13: MDD motor with straight feedback connector Angle connector INDRAMAT supplies and delivers the angle connectors so that the output direction of the cable, once inserted into the flanged socket, is side B of the motor. Fig. 2.14: MDD motor with angle connector (output direction at delivery is side B) RIGHT LEFT SIDE A SIDE B FAABGANG FAGERADSTECK Feedback connector FAWINKSTECK Feedback connector 2. Technical Explanations • DOK-MOTOR*-MDD********-PRJ1-EN-E1,44 • 12.96 23 The user can change the output direction. Just release the four fixing screws (see Figure 2.15). The connector part can now be turned in increments of 90° into the position desired. Fig. 2.15: Labelling the parts of the connector 2.3. Electrical Features Terminal diagram The terminal diagram shown in Figure 2.16 is purely schematic. It represents a checklist of all the necessary electrical connections to operate the MDD AC servo motor. Fig. 2.16: Schematic terminal diagram The following electrical connections are on the MDD motor: • power connection • feedback connection Make sure that neither the gasket nor the cable cores of the cable are damaged when re-tightening the screws. FABEZSTECK Mounting screws Connector housing connector part with screwed cap
