Normal = Less than 1 Vdc, approximately 0.75 Vdc Fan
Failure = voltage alternates between 32 Vdc and 0.75 Vdc
To use LED’s for quick status information at the unit,
purchase a BAYSENS110* ZSM and connect wires with
alligator clamps to terminals 6 through 10. Connected
each respective terminal wire (6 through 10) from the Zone
Sensor to the unit J6 terminals 6 through 10.
Note: If the system is equipped with a programmable
zone sensor, BAYSENS119* the LED indicators will
not function while the BAYSENS110* is connected.
Resetting Cooling and Heating Lockouts
Cooling Failures and Heating Lockouts are reset in an
identical manner. Method 1 explains resetting the system
from the space; Method 2 explains resetting the system at
the unit.
Note: Before resetting Cooling Failures and Heating
Lockouts check the Failure Status Diagnostics by
the methods previously explained. Diagnostics will
正常=小于1 Vdc，约0.75 Vdc风扇
故障=电压在32 Vdc和0.75 Vdc之间交替
要使用LED显示装置的快速状态信息，
购买BAYSENS110*ZSM，并用
鳄鱼夹连接到端子6到10。有联系的
各区域的各端子线（6至10）
传感器至装置J6端子6至10。
注意：如果系统配备了可编程控制器
区域传感器，BAYSENS119*LED指示灯将点亮
连接BAYSENS110*时不工作。
重置冷却和加热锁定
冷却故障和加热锁定会在
一模一样。方法1解释了重置系统
从太空；方法2解释了在以下位置重置系统：
单位。
注意：在重置冷却故障和加热之前
锁定通过诊断检查故障状态
前面解释的方法。诊断将
